README

A comprehensive TUI grid rendering library for PHP 8.3+, ported from the Charmbracelet ecosystem (bubbletea, bubble-grid, lipgloss). Provides 200+ components for building rich terminal user interfaces.

Installation

composer require sugarcraft/sugar-dash

Core Concepts

Interfaces & Contracts

Type	Description	Key Methods
`Item`	Anything that can be placed in a StackedGrid and rendered as a string	`render(): string`
`Sizer`	An Item that knows its own dimensions (extends Item)	`setSize(int $width, int $height): Sizer`, `render(): string`

Configuration Classes

Type	Description	Key Properties
`Options`	Grid-level configuration options	`$fitScreen: bool` (default: true)
`ItemOptions`	Per-item placement options within StackedGrid	`$column: int` (0-based), `$expandVertical: bool`
`ItemWithOptions`	Internal pairing of Item + ItemOptions	`$item: Item`, `$options: ItemOptions`

Layout Enums

Type	Values
`LayoutDirection`	`Horizontal`, `Vertical`
`SplitDirection`	`Horizontal`, `Vertical`
`AlignItems`	`Start`, `End`, `FlexStart`, `FlexEnd`, `Center`, `Stretch`, `Baseline`
`FlexDirection`	`Row`, `Column`, `RowReverse`, `ColumnReverse`
`FlexWrap`	`NoWrap`, `Wrap`, `WrapReverse`
`HAlign`	`Left`, `Right`, `Center`
`VAlign`	`Top`, `Middle`, `Bottom`
`JustifyContent`	`Start`, `End`, `FlexStart`, `FlexEnd`, `Center`, `SpaceBetween`, `SpaceAround`, `SpaceEvenly`
`FlowchartNodeType`	`Process`, `Decision`, `StartEnd`, `InputOutput`, `Connector`, `Data`
`EdgeStyle`	`Solid`, `Dashed`, `Dotted`, `Bold`
`NetworkShape`	`Circle`, `Square`, `Diamond`, `Hexagon`, `Star`
`WaterfallBarType`	`Positive`, `Negative`, `Total`, `Subtotal`

Layout & Structural Components

Layout Containers

Type	Description	Key Methods/Factories
`StackedGrid`	Multi-column stacked grid layout with items in columns	`addItem(Item, ItemOptions)`, `new(Options)`
`GridLayout`	CSS Grid-style layout with rows/columns/gaps	`columns(int, items)`, `rows(int, items)`, `withGap()`, `withItem()`
`FlexLayout`	Flexbox-style layout with direction/wrap/justify	`row()`, `column()`, `withJustify()`, `withAlignItems()`, `withGap()`
`VStack`	Vertical stack with alignment and spacing	`new(...items)`, `spaced(int, ...items)`, `centered(...items)`, `right(...items)`
`HStack`	Horizontal stack with spacing and alignment	`new(...items)`, `spaced(int, ...items)`, `centered(...items)`
`ZStack`	Layered stack (items on top of each other)	`new(...items)`, `left(...items)`, `right(...items)`, `top(...items)`, `bottom(...items)`
`Stack`	Basic vertical stack	`new(...items)`, `spaced(int, ...items)`

Border & Frame Components

Type	Description	Key Methods/Factories	GIF
`Frame`	Bordered frame wrapping any Item with title/padding	`new(Item)`, `withBorder()`, `withBorderColor()`, `withPadding()`, `withTitle()`
`Panel`	Panel with header/content/footer sections	`new(Item	string)`,` titled(Item
`BoxDrawing`	Unicode box-drawing frame generator	`new(?string)`, `titled(string)`, `double()`, `rounded()`, `bold()`, `withStyle()`, `withBorderColor()`, `withBgColor()`
`BorderText`	Text with ASCII-art border characters	`new(Item	string)`,` withBorders(Item
`Divider`	Horizontal or vertical divider line	`new(?string)`, `h(?string)`, `v(?string)`, `withStyle()`, `withLabel()`, `withColor()`

Spacing & Layout Helpers

Type	Description	Key Methods/Factories
`Spacer`	Empty space filler with optional fill character	`new(int $width, int $height)`, `dotted(int)`, `dashed(int)`, `vertical(int, int)`
`LayoutItem`	Item with flex properties for layouts	`flex(Item, int)`, `fixed(Item)`
`Shadow`	Drop shadow effect wrapping any Item	`new(Item)`, `withStyle()`, `withColor()`, `withOffset()`, `withHeavy()`, `withNoShadow()`
`Segment`	7-segment digital display	`new(string)`, `withDigitWidth()`, `withOnColor()`, `withOffColor()`

Data Visualization (Charts)

Chart Components

Type	Description	Key Methods/Factories
`Chart`	Bar/line chart with axes, labels, grid	`new(dataPoints, type)`, `withDataPoints()`, `withType()`, `withColor()`, `withGrid()`, `withShowValues()`
`AreaChart`	Area chart for time series data	`new(series)`, `withShowGrid()`, `withShowLegend()`, `withMaxValue()`, `withStacked()`
`Area`	Stacked area chart with gradient fills	`new(dataPoints)`, `sample(int)`, `withDataPoints()`, `withStacked()`, `withShowLegend()`
`AreaPoint`	Area chart data point: `label: string`, `value: float`, `y0: float	null`
`Bar`	Horizontal status bar with colors	`new(string)`, `withContent()`, `withForeground()`, `withBackground()`, `withAlign()`, `withBorders()`
`CandlestickChart`	Financial candlestick chart	`new()`, `withCandle()`, `addCandle()`, `withShowGrid()`, `withShowVolume()`
`Candlestick`	Single OHLC candlestick: `label`, `open`, `high`, `low`, `close`	`bullish()`, `bearish()`, `isBullish()`
`Donut`	Donut chart with proportional segments	`new(data)`, `mocha(data)`, `withSize()`, `withCenterLabel()`, `withShowPercentage()`
`Gauge`	Horizontal progress bar / gauge	`new(float $ratio)`, `withWidth()`, `withFilledColor()`, `withEmptyColor()`, `withPercentage()`
`GaugeChart`	Circular gauge chart
`GaugeCircle`	Circular gauge visualization
`HeatMapChart`	2D heatmap with color gradient	`new(data)`, `sample()`, `withRowLabels()`, `withColumnLabels()`, `withLowColor()`, `withHighColor()`
`Heatmap`	Heat map visualization with legend	`new(data)`, `sample()`, `withLegend()`, `withValues()`, `withLowColor()`, `withHighColor()`
`HeatmapCalendar`	GitHub-style calendar heatmap	`new(data)`, `sample()`, `withLowColor()`, `withHighColor()`, `withEmptyChar()`
`RadarChart`	Radar/spider chart for multi-axis data	`new(labels, series)`, `withSize()`, `withGridLines()`, `withShowLabels()`
`Sankey`	Sankey diagram for flow visualization	`new()`, `addNode()`, `addFlow()`, `withHorizontal()`, `withShowLabels()`
`SankeyNode`	Node in Sankey diagram: `id`, `label`, `value`, `color`
`SankeyFlow`	Flow connection: `source`, `target`, `value`, `color`
`Sparkline`	Inline sparkline chart	`new(data)`, `withData()`, `withWidth()`, `withHeight()`, `withDataPoints()`, `withFill()`
`SparklineBar`	Bar-style sparkline
`SparklineArea`	Area-style sparkline
`SparkArea`	Spark area chart
`Sunburst`	Sunburst chart visualization
`Treemap`	Treemap chart visualization
`TreemapLeaf`	Leaf node in treemap
`TreeViz`	Tree visualization
`Waterfall`	Waterfall chart
`WaterfallItem`	Waterfall bar item
`FunnelChart`	Funnel chart visualization
`Funnel`	Funnel visualization component
`Partition`	Partition chart
`PartitionSegment`	Partition segment
`Bullet`	Bullet chart
`NProgress`	Progress bar component
`Meter`	Meter/gauge component
`Rating`	Star rating display
`OHLC`	Open-High-Low-Close data
`OHLCPoint`	OHLC data point
`TableChart`	Table-based chart
`TableBordered`	Bordered table
`TableZebra`	Zebra-striped table
`MetricsGrid`	Grid of metric displays
`ProgressList`	List of progress items

Form & Input Components

Type	Description	Key Methods/Factories
`Checkbox`	Checkbox group with single/multi-select	`new(options)`, `withSelectedIndex()`, `withOptionChecked()`, `withMultiSelect()`, `withCheckedColor()`
`Input`	Text input field	`new(?string)`, `labeled()`, `password()`, `withValue()`, `withPlaceholder()`, `withLabel()`, `withError()`, `withBorderColor()`
`Select`	Dropdown select component	`new(options)`, `withSelectedIndex()`, `withOptions()`, `withSelectedColor()`
`Textarea`	Multi-line text area
`Slider`	Slider control
`Toggle`	Toggle switch
`SwitchComponent`	Switch component
`Radio`	Radio button
`Label`	Form label
`Chip`	Chip/tag component
`ChipGroup`	Group of chips
`ComboBox`	Combo box
`DatePicker`	Date picker
`ColorPicker`	Color picker
`Dropdown`	Dropdown menu

Feedback & Status Components

Type	Description	Key Methods/Factories
`Alert`	Alert/message box (info, warning, error, success)	`new(string)`, `info()`, `warning()`, `error()`, `success()`, `withMessage()`, `withTitle()`, `withBorderColor()`
`Badge`	Badge/tag component	`new(string)`, `success()`, `warning()`, `error()`, `info()`, `withStyle()`, `withSize()`, `withIcon()`
`BadgeGroup`	Group of badges
`LoadingText`	Animated loading text
`Modal`	Modal dialog
`Notification`	Toast notification
`Progress`	Progress indicator
`ProgressBar`	Progress bar
`ProgressRing`	Circular progress indicator
`Skeleton`	Loading skeleton
`Spinner`	Loading spinner
`StatusIndicator`	Status indicator dot
`Toast`	Toast message
`Tooltip`	Tooltip popup
`Popover`	Popover content
`NProgress`	npm-style progress bar
`Marquee`	Scrolling marquee text
`Cursor`	Terminal cursor
`Buffer`	Terminal buffer

Navigation Components

Type	Description	Key Methods/Factories
`Breadcrumb`	Breadcrumb navigation	`new(items)`, `fromPath()`, `withItems()`, `withSeparator()`, `withActiveIndex()`
`Tabs`	Tabbed interface	`new(tabs)`, `withSelectedIndex()`, `withActiveColor()`, `withTabs()`
`TabsVertical`	Vertical tab navigation
`Pagination`	Pagination controls
`PaginationSimple`	Simple pagination
`Stepper`	Step progress indicator
`Navbar`	Navigation bar
`Sidebar`	Sidebar navigation
`Menu`	Menu component

Layout Helper Components

Type	Description	Key Methods/Factories	GIF
`Card`	Card container component
`Cover`	Cover layout
`Jumbotron`	Jumbotron hero section
`CTA`	Call-to-action component
`Avatar`	User avatar
`AvatarGroup`	Group of avatars
`Profile`	User profile card
`Pricing`	Pricing table
`Testimonial`	Testimonial quote
`Features`	Feature grid
`EmptyState`	Empty state placeholder
`Footer`	Page footer
`Header`	Page header
`ListComponent`	List renderer
`Stat`	Single stat display
`Stats`	Statistics display
`Metric`	Metric display
`ActivityFeed`	Activity feed
`Comment`	Comment component
`LogViewer`	Log file viewer
`Console`	Terminal console
`CommandPalette`	Command palette
`Editor`	Text editor
`Terminal`	Terminal emulator
`Log`	Log entry
`Screen`	Terminal screen
`Viewport`	Viewport component
`Window`	Window frame
`Wizard`	Multi-step wizard
`WizardStep`	Wizard step
`Drawer`	Drawer panel
`Accordion`	Accordion/collapsible
`Calendar`	Calendar view
`Clock`	Digital clock
`Timer`	Countdown timer
`Stopwatch`	Stopwatch
`Video`	Video player
`Audio`	Audio player
`Image`	Image display
`Picture`	Picture frame
`Icon`	Icon display
`QRCode`	QR code
`Barcode`	Barcode

Text Components

Type	Description	Key Methods/Factories
`Text`	Word-wrapped text content	`new(string)`, `withMaxWidth()`, `withTrim()`, `withHorizontalAlign()`
`Code`	Code block with syntax highlighting
`Kbd`	Keyboard key display
`Paragraph`	Paragraph text
`Markdown`	Markdown rendering
`FigletText`	ASCII art text (FIGlet style)
`ASCIIBanner`	ASCII banner text
`Emoji`	Emoji display
`HexDump`	Hex dump viewer
`Highlight`	Syntax highlighted code
`DotMatrix`	Dot matrix display
`Pictogram`	Pictogram display
`Boxer`	Boxing text effect

Diagram & Visualization Components

Type	Description	Key Methods/Factories	GIF
`ClassDiagram`	UML class diagram
`Dendrogram`	Dendrogram/tree diagram
`DendrogramNode`	Node in dendrogram
`Flowchart`	Flowchart diagram
`FlowchartNode`	Node in flowchart
`Gantt`	Gantt chart
`Graph`	Graph visualization
`HexDump`	Hex dump view
`Ladder`	Ladder diagram
`Leaderboard`	Leaderboard display
`MindMap`	Mind map visualization
`Network`	Network diagram
`NetworkNode`	Node in network
`OrgChart`	Organization chart
`PERT`	PERT chart
`Sequence`	Sequence diagram
`Timeline`	Timeline display
`TimelineViz`	Timeline visualization
`TimelineNode`	Node in timeline
`Tree`	Tree structure
`TreeNode`	Tree node
`WordCloud`	Word cloud visualization
`Diff`	Diff view
`Bubble`	Bubble chart
`BubblePoint`	Bubble chart point
`Canvas`	Drawing canvas
`Scrollbar`	Custom scrollbar

Event Types

Type	Description	Key Properties
`Event`	Base event class
`EventHandler`	Event handler callback
`EventDispatcher`	Event dispatcher
`FocusEvent`	Focus event
`KeyEvent`	Keyboard event
`MouseEvent`	Mouse event
`PasteEvent`	Paste event
`ResizeEvent`	Resize event
`Focus`	Focus state management
`Key`	Key representation
`KeyAction`	Key action
`KeyMap`	Key mapping
`State`	Application state

Theme & Styling

Type	Description	Key Methods
`Theme`	Theme management with pre-defined themes	`dark()`, `dracula()`, `oneDark()`, `githubDark()`, `light()`, `foreground()`, `background()`, `primary()`, `bar()`, `text()`

Usage Example

use SugarCraft\Dash\Grid\{StackedGrid, Frame, VStack, Text, Panel, Options, ItemOptions};

// Create a stacked grid layout
$grid = new StackedGrid(new Options(fitScreen: true));

// Add items to columns
$grid->addItem(
    Frame::new(
        VStack::centered(
            Text::new('Welcome to SugarDash'),
            Text::new('Build beautiful TUIs')
        )
    )->withPadding(1),
    new ItemOptions(column: 0, expandVertical: true)
);

// Add a panel to the second column
$grid->addItem(
    Panel::titled(
        Text::new('This is a panel'),
        'Dashboard'
    ),
    new ItemOptions(column: 1)
);

// Set size and render
$grid->setSize(80, 24);
echo $grid->render();

Testing

cd sugar-dash && composer install && vendor/bin/phpunit

GIF Demos

Demo	Description
	Layout containers demo
	Charts demo
	Form demo
	Navigation demo
	Status indicators demo
	Text components demo
	Time components demo
	UI components demo
	Complex layout demo
	Data display demo
	Devtools demo
	Interactive components demo
	Media components demo
	Metrics display demo
